Take your trail rides to the next level on the updated Lumen 910 eMTB. With a lightweight design that rides like a playful, non-powered trail bike combined with the power of the new TQ HPR60, you’ll have the best of both worlds as you push the pace on the singletrack.
The Lumen has always been beloved for its agile, flickable, responsive ride quality, making it feel more like a traditional MTB than a full-powered e-MTB. But now it’s 20% stronger than ever thanks to the new HPR60 motor unit which boosts torque from 50Nm to 60Nm for thrust you can feel gripping out of hairpins and powering over the steepest inclines. It’s the extra spice that brings Lumen 910 into its own in the lightweight e-MTB category.
Lightweight doesn’t mean short laps either. Every Lumen 910 comes with a 160Wh Range Extender Battery to complement the 360Wh main battery for peace of mind to take your ride further. The size of a small water bottle, it easily attaches with a quick-release mount or can be stowed in a small pack to have along on the ride in case you need it. And not to worry, Lumen’s light weight and drag-free motor mean that if you play til the tank is empty, you’ve still got a fun and pedalable bike to spin back to the trailhead.
This Lumen 910 features a brightly illuminated black and white display and is specced with 140mm of front and 130mm of rear travel, SRAM Transmission drivetrain, and powerful Motive Bronze brakeset to equip you for elite-level rides without breaking the bank.
Frame
Carbon HMX, Integrated Suspension Technology, Flex Pivot, adjustable head angle, Syncros Cable Integration System, TQ HPR60, UDH interface, 12x148mm with 55mm chainline
Travel
Front: 140 mm / Rear: 130 mm
Fork
Fox 34 Rhythm Grip, 3P, Kabolt 15x110mm axle, tapered steerer, Reb. Adj, Lockout
Rear Shock
Fox Nude 6 EVOL Trunnion, SCOTT custom w. travel, geo adj., 3 modes: Lockout-Traction Control-Descend, low speed Adj., Custom large Air volume, Reb. Adj., Bearing Hardware, T165X45mm
Remote System
SCOTT TwinLoc Technology, 3 Suspension modes
Drive Unit
TQ HPR60 Mid Motor drive 60Nm max Torque, EU: 25kmh - INT: 20mph - US: 28mph
Battery
TQ Internal 360Wh
Display
TQ HPR, Bluetooth, ANT+, Dedicated Smartphone app
Charger
TQ 4A 100-240V
Rear Derailleur
SRAM S1000 Eagle AXS Transmission 12 Speed, Wireless Electronic Shift System
Shifters
SRAM AXS Pod Controller
Crankset
Praxis alloy
Chainguide
e*thirteen, e*spec Slider
Chainring
SRAM 104BCD 34T
Chain
SRAM GX Eagle Transmission
Cassette
SRAM Eagle XS-1270 Transmission, 10-52T
Brakes
SRAM Motive Bronze 4-Piston
Front Disc Rotor
SRAM HS2 CL, 180mm
Rear Disc Rotor
SRAM HS2 CL, 180mm
Grips
Syncros Performance XC Lock-On
Handlebar
Syncros Fraser 2.0 DC alloy 6061 D.B. Mini Rise, back sweep 8°, 740mm Syncros Performance XC lock-on grips
H'stem
Syncros DC 2.0 Syncros Cable Integration System 0° rise, 6061 alloy, 31.8mm, 1 1/8"
Seatpost
Syncros dropper post SP-M302-AL2, 31.6mm
Seat
Syncros Tofino R 1.5
Headset
Syncros - Acros Angle adjust & Cable Routing HS System, Stainless, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Front Hub
Formula CL-811, 15x110mm
Rear Hub
Formula CL-148S, 12x148mm
Spokes
Stainless Black
Front Rim
Alex Rims X-30S 32H, Sleeve Joint, Tubeless ready
Rear Rim
Alex Rims X-30S 32H, Sleeve Joint, Tubeless ready
Tires
Schwalbe Wicked Will EVO, TLE 29 x 2.40
Approx weight in KG
17.8 Tubless setup without RE (1.1kg)
Max. System Weight
130kg
The overall weight includes the bike, the rider, the equipment and possible additional luggage.
To reduce production and delivery times the supplier sometimes have to make last-minute changes to product specifications. These updates may not always be reflected in the product descriptions or images on our website.
