FRAME
VOLT 4 BAR HORST LINK ALLOY FRAMESET WITH INTEGRATED BATTERY
HYDROFORMED TUBING / INTERNAL CABLE ROUTING / BOOST 148MM WITH THRU AXLE
FORK
ROCKSHOX FS LYRIK DEBONAIR+ 29" 150MM
ROCKSHOX LYRIC / FS LYRK BSE 29 SB 150 EDFB 44 D1 / FS LYRIK BASE RUSH RC 29″ BOOST 15X110 MXL STEALTH DEBONAIR+ 150 E-MTB DECAL DIF BLACK 44 OFFSET 1.5 TAPER D1
REAR SHOCK
ROCKSHOX SUPER DELUXE SELECT RS 140MM
CHAINWHEEL
ANANDA EP01A 34T
ANANDA EP01A 34T / 12 SPEED / ALLOY CRANK / STEEL CHAINRING
DERAILLEUR REAR
SHIMANO XT RD-M8100 12 SPEED
SHIFTER RIGHT
SHIMANO XT SL-M8100-R 12 SPEED
CHAIN
SHIMANO CN-M6100-12
FREEWHEEL
SHIMANO DEORE M6100-12 10-51T
SPEED
12 SPEED
CRANK
ANANDA EC38-F5-ISIS-165 (L)+(R), ISIS SCREW
BATTERY
GREENWAY 630WH
CONTROLLER
ANANDA D18 TFT DISPLAY
DISPLAY
ANANDA D18 TFT DISPLAY
SENSOR
ANANDA
MOTOR
ANANDA TR M230 350W/100NM WITH 32KM/H ASSIST
BRAKE LEVER
SHIMANO BL-MT401
BRAKE FRONT
SHIMANO BR-MT420 4 PISTON WITH 203MM
BRAKE REAR
SHIMANO BR-MT420 4 PISTON WITH 203MM
RIMS
PRIME SL 27 TLR RIM 32H
TR PRIME SL 27 / 29er / MATT BLACK / DOUBLE WALL W/EYELETS / 32H / TL-READY / F/V
HUB FRONT
SHIMANO HB-MT400-B
THRU, 14Gx32H-M15x110, Boost
HUB REAR
SHIMANO FH-MT410-B
THRU, 14Gx32H-M12x148, Boost
SPOKES
STAINLESS BLACK 14Gx290mm / 14Gx288mm
TUBE
29″ F/V
TYRES
VITORIA AGARRO 29" × 2.4"
VITORIA AGARRO 29″ × 2.4″ TRAIL C2.0 TYRES
GRIP
TR SLIDELOCK GRIP
HANDLEBAR
TR PRO ALLOY RISER BAR 780MM
PROMAX HB-3188DB R15 780MM
HANDLEBAR STEM
TR PRO ALLOY STEM
DA-205 3D FORGED AL6061 / 31.8mm BAR BORE / 28.6mm CLAMP I.D / 6 DEGREE RISE / S = 60mm / M/L = 80mm / XL = 100mm
HEADSET
FSA NO.57 – HBS / NO.57- ACB
SPACER
10mm X 2 PCS
SADDLE
SR A084HR0018014
SEAT POST
X-FUSION MANIC WITH REMOTE 34.9
X-FUSION MANIC LC S = 125MM / M = 150mm / L+XL = 170MM WITH PLASTIC REMOTE 34.9mm
SEAT CLAMP
NEW MX-95RT ALLEN KEY TYPE
FEATURES
Utility Mount Under the Top Tube for additional storage
Clearance for 2.6” tires (Brand and model dependent)
SRAM UDH Hanger Standard
Tubeless Ready Rims and Tires across the range
Progressive Trail Geometry
Internal cable routing
630Wh removable battery
100Nm, 350W Motor
MOTOR SPECS
Weight: 2.8 Kg
Construction: Gear Drive
Shaft Standard: ISIS
Rated Power: 350 W
RPM: 120
Max Torque: 100 Nm
Max efficiency: ≥80%
Compact and lightweight
High precision torque sensor
To reduce production and delivery times the supplier sometimes have to make last-minute changes to product specifications. These updates may not always be reflected in the product descriptions or images on our website.
