MERIDA eOne Sixty SL 6000 (2026)

FRAME
eONE-SIXTY SL CF4 I
material: carbon
160mm suspension travel
29x2,4" max. wheelsize
148x12mm axle standard
fixed battery

FORK
Marzocchi Z1 eMTB
Air
160mm suspension travel
Tapered
44mm fork offset
29x2.6" max wheelsize

SHOCK
Marzocchi Bomber Air
platform

BRAKES
Shimano Deore
4 piston

ROTORS
Shimano RT64, 203mm

HEADSET
Acros ICR MERIDA INTEGRATED neck w/ Blocklock

HANDLEBAR
MERIDA EXPERT eTR
780mm width

HANDLEBAR STEM
MERIDA EXPERT eTR II
material: aluminium
35mm diameter
0° stem angle
Supernova mount
40 mm all sizes

GRIPS
MERIDA EXPERT EC

DERAILLEUR (R)
Shimano Deore

SHIFTERS
Shimano SL -MT500-IL / Shimano Deore

SEAT POST
MERIDA COMP TR III
34.9mm diameter
0mm setback *

SEAT CLAMP
MERIDA EXPERT

SADDLE
MERIDA COMP SL
V-mount
incl. MERIDA minitool

CHAIN
Shimano Deore M6100

CHAINWHEEL
FSA 1x Alloy Spider + Mega Tooth steel chain ring
34 teeth

CRANK
FSA CK-220 wide E-Bike Forged Crankset
165mm for all sizes

FREEWHEEL
Shimano Deore
10-51 teeth
12 speed

HUBS
Shimano TC500
15x100mm width front hub
32 spoke holes
Centerlock
12x148mm width rear hub
32 spoke holes
Centerlock

RIMS
Reynolds 309 Enduro Comp
30mm inner width
material: aluminium
Tubeless ready (tubeless tape installed)
29"

TYRE FRONT
Maxxis Assegai
29x2.5 "
fold
TR EXO+ 3C MaxxGrip

TYRE REAR
Maxxis Minion DHR II
29x2.4 "
fold
TR EXO+ 3C MaxxTerra

AXLES
MERIDA EXPERT TR
including removeable lever, 6/4mm allen key

SPOKES
Black stainless
black nipples

LIGHT FRONT
USB rechargable Chance Good CG-119PG-BLACK(1)

LIGHT REAR
USB rechargable Chance Good CG-404RG-BLK

FENDER
RF-001 mini fender

DRIVE UNIT
Bosch Performance Line SX

BATTERY
Bosch CompactTube
400Wh

DISPLAY
Bosch Kiox 400C

APPROX. WEIGHT
20.9 kg

MAX. WEIGHT
140 kg
